UMC Series
The most efficient and intelligent machining concept for multi-sided high performance machining, increase productivity, flexibility and repeatability.
The high rigid and heavy duty roller type linear motion guideways on 3 axes provide low starting inertia, low friction and high acceleration, rates optimize servo drive and ensure machine response immediately and precisely for high speed cutting requirements, especially in rapid positioning and contouring cutting.
- Time saving thanks to multi-sided machining without having to re-set.
- Maximum productivity thanks to rapid movement and high acceleration.
- Unlimited flexibility and versatility when manufacturing individual parts.
- Maximum stability thanks to optimum load distribution.
- Highest machine precision repeatability thanks to avoidence of any axis overlapping.
- Totally enclosed guarding.
UMC-1000 | ||
|---|---|---|
| Travel | ||
| X / Y / Z Axis | mm. | 1000 x 800 x 700 |
| Distances | ||
| Vertical: Spindle nose to table | mm. | 150 ~ 850 |
| Horizontal: Spindle centre to table | mm. | 50 ~ 750 |
| Indexing Table | ||
| Dimension | mm. | 1000 x 800 |
| To floor distance | mm. | 1000 |
| Maximum load | kg | 1500 |
| Indexing increment | 0.001° x 360,000 | |
| T slots (no x width x pitch) | 7 x 18H x P100 | |
| Motor Head Spindle | ||
| Speed | rpm | 16,000 (20,000) |
| Power | kw | 17.2 (21.4) |
| Taper | SK40 (HSK-A63) | |
| Indexing increment | 0.001° x 360,000 | |
| Front bearing diameter | mm. | 70mm |
| Feedrate | ||
| Rapid | m/min | 24 /24 /24 |
| Cutting | m/min | 10 |
| ATC | ||
| Tool holder | SK40 | |
| Pull stud | MAS 403P40T1 | |
| Tools | 40 | |
| Max. Dia / length / weight | Ø120mm/300mm/7kg | |
| General | ||
| Power requirement | kva | 40 |
| Floor size and height | m | 3.7 x 4.5 x 3 |
| Net weight | kg | 15000 |
Specifications subject to change without notice
